Description
The HWCA-229NF-CPR-RA is a WR-229 waveguide to SMA Female coaxial adapter with a 3.3 GHz to 4.9 GHz frequency range. This adapter offers a robust design with Low VSWR and Low Insertion Loss with a CPR229 flange. HASCO waveguide to SMA coaxial transitions are designed to provide enhanced RF performance, resulting in characteristics like low insertion loss and low VSWR. When selecting a waveguide to coaxial adapter, choosing the correct connector type, flange materials, flange types and flange profiles is essential to achieving your desired RF performance. HASCO Cage Code: 0T8L4
« DatasheetSpecifications
Item | Specification |
|---|---|
| Frequency Range | 3.3 - 4.9 GHz |
| VSWR | 1.25:1 Max |
| Insertion Loss | 0.20 dB Typical |
| Waveguide | WR-229 |
| Flange | CPR229 |
Material Specifications
Item | Specification |
|---|---|
| Material | Aluminum Alloy |
| Finish | Chemical Film per MIL-C-5541, Clear |
- Adapter Body Style:
- Right Angle
- Connector 1 Gender:
- Female
- Connector 1 Mount:
- Rectangular Flange
- Connector 1 Series:
- SMA
- Flange Type:
- CPR229F
- Frequency, Max:
- 4.9 GHz
- Frequency, Min:
- 3.3 GHz
- Type:
- Between-Series
- Waveguide Size:
- WR-229
PRODUCT DETAILS
The HWCA-229NF-CPR-RA is a WR-229 waveguide to SMA Female coaxial adapter with a 3.3 GHz to 4.9 GHz frequency range. This adapter offers a robust design with Low VSWR and Low Insertion Loss with a CPR229 flange. HASCO waveguide to SMA coaxial transitions are designed to provide enhanced RF performance, resulting in characteristics like low insertion loss and low VSWR. When selecting a waveguide to coaxial adapter, choosing the correct connector type, flange materials, flange types and flange profiles is essential to achieving your desired RF performance. HASCO Cage Code: 0T8L4
« DatasheetSpecifications
Item | Specification |
|---|---|
| Frequency Range | 3.3 - 4.9 GHz |
| VSWR | 1.25:1 Max |
| Insertion Loss | 0.20 dB Typical |
| Waveguide | WR-229 |
| Flange | CPR229 |
Material Specifications
Item | Specification |
|---|---|
| Material | Aluminum Alloy |
| Finish | Chemical Film per MIL-C-5541, Clear |
