HVNA26-35NMD-35J-24 3.5mm NMD Female to 3.5mm Female VNA Cable

3.5mm NMD Female to 3.5mm Female Precision VNA Test Cable, Low Loss, Phase Stable vs. Flexure, 24 Inches

$616.66

Part #:

HVNA26-35NMD-35J-24

Brand:

HASCO Components

Weight:

15.00 Ounces

Shipping:

Calculated at checkout

Current Stock:

For quantities greater than current stock levels, please contact customer service at 1-888-498-3242

Pricing by Quantity:

QUANTITY

1 to 9

Buy 10 - 24

Buy 25 - 49

Buy 50 - 99

Buy 100 - 249

Buy 250 - 499

Buy 500 or above

PRICE

$616.66

$598.16

$580.22

$562.81

$545.93

$529.55

$513.66

PRODUCT DETAILS
Warranty Information

Description

HASCO Part Number: HVNA26-35NMD-35J-24

RF Cable Assemblies offered by HASCO Components are available in a variety of RF connectors and custom lengths for production and testing environments. HVNA26-35NMD-35J-24 is an RF cable assembly manufactured by HASCO Components. This is a Lab Grade VNA test cable assembly HVNA26-35NMD-35J-24 has 3.5mm NMD Female to 3.5mm NMD Female connectors. This RF Assembly is rated up to 26.5 GHz. For additional technical information please refer to the datasheet. HASCO Cage Code: 0T8L4

« Click Here for the HVNA26-35NMD-35J-24 Datasheet

FEATURES:

RoHS Compliant
Extra rugged and long-life performance
High stability for test lab precision measurements
Negligibile changes in phase & amplitude after flexing
Phase Stability Vs. Flexure: ± 2° @ 26.5 GHz
(When wrapped 90°around a 2" radius mandrel)
Insertion Loss: < 2.1 dB @ 26.5 GHz
Excellent Amplitude Stability: < ± 0.4 dB through 26.5 GHz

ELECTRICAL SPECIFICATIONS:

Max Frequency (GHz)	26.5
Capacitance (pF/ft)	29.4
Velocity Propagation (%)	70
VSWR	1.35:1
Time Delay (ns/Ft)	1.40
Impedance (Ohms)	50
Frequency (GHz)	2	6	10	18	26.5
Power CW (Watts)	420	215	140	125	75
Phase Stability vs. Flexure (°)	±0.19	±.57	±.94	±1.7	±2.5

MECHANICAL SPECIFICATIONS:

Cable Max Dia. (Inch)	0.6
Min. bend radius (Inch)	1.5
Recommend Bend Radius (Inch)	2
Temperature Range (°C)	-40 to +105

MATERIALS AND FINISHES:

DESCRIPTION	MATERIALS	FINISH OR COLOR
Cable Outer Braid	Polyester-PET	Black
Marker	Mil-l-23053	White
Contacts	BeCu	Gold Plated
Insulators	PEEK	None
Connector Bodies (35P)	Stainless Steel & Aluminum Alloy	Passivated / Electrophoresis
Connector Bodies (NMD35)	Stainless Steel	Passivated
Connector Nuts (35P)	Stainless Steel & Aluminum	Passivated
Gasket	Silicon Rubber	A-A-59588

It is important to take care of your test cables for optimal long-term use and accuracy of your test equiment. For more information, please follow this link to read/download the document “Handling High Performance Coax Cables.” Click this link: https://www.hasco-inc.com/pages/resource-center/handling-high-performance-coax-cables.html

*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242

Cable Diameter:: .600
Cable Length (Inch):: 24
Cable Series:: HVNA26
Cable Type:: Amplitude Stable
Cable Type:: Phase Stable
Connector 1 Gender:: Female
Connector 1 Series:: 3.5mm NMD
Connector 1 Style:: Straight
Connector 2 Gender:: Female
Connector 2 Series:: 3.5mm
Connector 2 Style:: Straight
Flex Type:: Flexible
Frequency, Max:: 26.5 GHz
Frequency, Min:: DC
Jacket Material:: PET
Type:: VNA
Velocity of Propogation (%):: 70
Connector 1 Series:: 3.5mm
Connector 2 Series:: 3.5mm NMD
