Description
« Click Here for the HA141AL-S1-S1-02 DatasheetFEATURES:
- RoHs Compliant
- Easily hand Formable to Final Shape
- SMA Straight Connector
- 100% VSWR test to 18 GHz
- 100% Hi-pot and continuity tests
- Cable Insertion Loss at +25°C: 0.8 dB + 0.065 x length (per inch)
ELECTRICAL SPECIFICATIONS:
|
Max Frequency (GHz) |
18 |
|
|
|
|
|
Capacitance (pF/ft) |
29 |
|
|
|
|
|
Velocity Propagation (%) |
70 |
|
|
|
|
|
RF Leakage @ 18 GHz (dB) |
>100 |
|
|
|
|
|
Impedance (Ohms) |
50 |
|
|
|
|
|
Power CW (Watts) |
Call for More Info |
|
|
|
|
MECHANICAL SPECIFICATIONS:
| Outer Conductor Diameter (Inch) | .141 |
|
Min. bend radius (Inch) |
.25 |
|
Recommend Bend Radius (Inch) |
1.5 |
|
Cable Temperature Range (°C) |
-55 to +85°C |
MATERIALS AND FINISHES:
|
DESCRIPTION |
MATERIALS |
FINISH OR COLOR |
|
Marker |
Mil-l-23053 |
Black |
|
Contacts |
Brass |
Gold Plated |
|
Insulators |
PTFE |
None |
|
Connector Bodies |
Brass |
Ni/Au |
|
Connector Nuts |
Stainless Steel |
Passivated |
|
Gasket |
Silicon Rubber |
A-A-59588 |
- Cable Diameter:
- .141
- Cable Length (Inch):
- 2
- Cable Series:
- HA141AL
- Connector 1 Gender:
- Male
- Connector 1 Series:
- SMA
- Connector 1 Style:
- Straight
- Connector 2 Gender:
- Male
- Connector 2 Series:
- SMA
- Connector 2 Style:
- Straight
- Flex Type:
- Hand Formable
- Frequency, Max:
- 18 GHz
- Frequency, Min:
- DC
- Jacket Material:
- Aluminum
- Download[PDF]:
- https://www.hasco-inc.com/content/Cables/Cable_Data_Sheets/HA141AL-S1-S1-L_Datasheet.pdf
