C-Band Stacked Array Antenna with Type N Female Connector - 4.4

C-Band Stacked Array Antenna with Type N Female Connector - 4.4 - 5.25 GHz

888-498-3242

Part #:

HAD-4825-O6D-08

Brand:

HASCO Components

Weight:

10.00 Ounces

Shipping:

Calculated at checkout

Out of stock - Call for availability

PRODUCT DETAILS
Warranty Information

Description

HASCO Part Number: HAD-4825-O6D-08

Features

• DC Grounded
• Hermetically Sealed
• Wall mounting kit included

The HASCO HAD-4825-O6D-08 is a C-Band stacked array antenna with a Type N female connector rated for 4.4 to 5.25 GHz. HASCO offers a versatile family of antennas. HASCO Components Cage Code: 0T8L4

« Click Here to View Datasheet

Electrical Specifications

Item	Specification
Frequency Range	4.4 - 5.25 GHz
VSWR	2.1:1
Impedance	50 Ω
Beamwidth	Azimuth: 360° Vertical 3 dB: 20 - 25°
Gain	6 dBi Nom
Rated Wind Velocity	120 mph (200 Kph)

Mechanical Specifications

Item	Specification
Lightning Protection	Antenna is DC grounded

Environmental Specifications

Item	Specification
Environment	Antenna is hermetically sealed

Materials

Item	Specification
Body	CRES

*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242

Connector 1 Mount:: Type N
Frequency, Max:: 5.25 GHz
Frequency, Min:: 4.4 GHz
Gender:: Female
Type:: Stacked Array Antenna
