SMA Male to SMA Male Test Cable using HSB42 Ultra Flexible Cable, Phase and Amplitude Stable vs. Flexure, 30 Inches

$121.30
Part #:
HSB42-S1-S1-30
Brand:
HASCO Components
Weight:
2.50 Ounces
Shipping:
Calculated at checkout
Current Stock:
12

For quantities greater than current stock levels, please contact customer service at 1-888-498-3242

Pricing by Quantity:

QUANTITY

10

25

50

PRICE

$117.65

$114.20

$110.70

ADD TO WISHLIST
*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242
Type:
Coax Cable Assemblies
Style:
Test Cable Assemblies
Application:
SMA Male to SMA Male Cable Assemblies
Construction:
Standard
Connector 1:
SMA Male
Connector 2:
SMA Male
Length (in.):
30
Impedance (Ohms):
50
PRODUCT DETAILS
WARRANTY INFORMATION
*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242
Part No: HSB42-S1-S1-30
SMA Male to SMA Male Test Cable using HSB42 Ultra Flexible Cable, Phase and Amplitude Stable vs. Flexure, 30 Inches

HASCO Part Number: HSB42-S1-S1-30

RF Cable Assemblies offered by HASCO Components are available in a variety of RF connectors and custom lengths for production and testing environments.  HSB42-S1-S1-30 is an RF cable assembly manufactured by HASCO Components.  The RF coax cable used is HSB42, an ultra flexible amplitude stable against flexure RF cable. HSB42-S1-S1-30 has SMA Male to SMA Male connectors. This RF Assembly is rated up to 26.5 GHz. For additional technical information please refer to the datasheet. Insulated Wire Cage Code: 59528

pdf-icon.png« Click Here for the HSB42-S1-S1-30 Datasheet pdf-icon.png« Click Here for the HSB42-S1-S1-30 Outline Drawing

FEATURES:

  •  RoHs Compliant

  •  Very flexible with bend radius of 1.95"

  •  Good performance even after 20,000 flex cycles

  •  Phase Stability Vs. Flexure: ± 2.95° @ 26.5 GHz
    (When wrapped 360°around a 1.95" radius mandrel)

  •  Available with Stainless Steel Armor

  •  Cable Insertion Loss: -.79 dB per Ft @ 26.5 GHz

  •  Excellent Amplitude Stability: < ± 0.1 dB through 26.5 GHz

ELECTRICAL SPECIFICATIONS:

Max Frequency (GHz)

26.5









Capacitance (pF/ft)

29.4









Velocity Propagation (%)

70









RF Leakage @ 18 GHz (dB)











Time Delay (ns/Ft)

1.40









Impedance (Ohms)

50









Frequency (GHz)

2

6

10

18

26.5

Power CW (Watts)

420

215

140

125

75

Phase Stability vs. Flexure (°)

±0.22

±.67

±1.11

±2

±2.95

MECHANICAL SPECIFICATIONS:

Cable Max Dia. (Inch)

0.195

Min. bend radius (Inch)

1.0

Recommend Bend Radius (Inch)

1.95

Temperature Range (°C)

-55 to +105

MATERIALS AND FINISHES:

DESCRIPTION

MATERIALS

FINISH OR COLOR

Cable Jacket

PVC

Blue

Marker

Mil-l-23053

White

Contacts

BeCu

Gold Plated

Insulators

PTFE

None

Connector Bodies

Stainless Steel

Passivated

Connector Nuts

Stainless Steel

Passivated

Gasket

Silicon Rubber

A-A-59588




Test #1: SMA Male to SMA Male, 30 inches, DC - 26.5 GHz



Test #2: SMA Male to SMA Male, 30 inches, DC - 26.5 GHz

Part No: HSB42-S1-S1-30
LTR
DESCRIPTION
DATE
APPR
THIS DRAWING IS A CONTROLLED DOCUMENT
DRAWN BY:
CHECKED BY:
APPROVED BY:
THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF HASCO COMPONENTS AND SHALL NOT BE REPRODUCED, COPIED NOR USED - IN WHOLE OR IN PART - AS THE BASIS FOR THE MANUFACTURE OR SALE OF OTHER ITEMS WITHOUT THE EXPRESS, RITTEN PERMISSION OF HASCO COMPONENTS.

MATERIALS:

SEE DATA SHEET

CAGE CODE:

HSB42-S1-S1-30

MATERIALS:

SEE DATA SHEET

SCALE:

NS

SIZE:

REV:
