Description
Features
• RoHs Compliant
The HASCO HA18A5WS-dB is a SMA Male to SMA Female Attenuator. This type of Attenuator is bidirectional. Attenuators like this HA18A5WS-dB are used to reduce or step down the power level of a signal while maintaining the waveforms integrity. The operating frequency for this model is DC to 18 GHz and is rated for 5 Watts. HASCO Cage Code: 0T8L4
« Datasheet
Item |
Specification |
||||||
|
Impedance |
50 Ohms |
||||||
|
Frequency Range |
DC to 18 GHz |
||||||
|
VSWR |
1.35:1 Max |
||||||
|
Power |
5 Watts |
||||||
|
dB Value |
4 dB |
||||||
|
Attenuation |
|
Item |
Specification |
|
Durability |
500 Cycles Min |
Item |
Specification |
|
Temperature Range |
-40°C to 125°C |
Material
Item |
Specification |
|---|---|
|
Body |
Passivated Stainless Steel |
|
Contact |
Gold plated BeCu |
|
Housing |
Anodized Aluminum |
- Adapter Body Style:
- Straight
- Connector 1 Gender:
- Male
- Connector 1 Series:
- SMA
- Frequency Range, Max:
- 18 GHz
- Frequency Range, Min:
- DC
- VSWR 1 Value:
- 1.35:1
- Power Rating:
- 5 Watts
- Type:
- Attenuator
- Body Material:
- Stainless Steel
- Body Plating:
- Passivated
- Center Contact Material:
- BeCu
- Center Contact Plating:
- Gold
- dB Value:
- 4 dB
- Connector 1 Series 2:
- SMA
- Connector 1 Gender 2:
- Female
- Connector 2 Series:
- SMA
- Connector 2 Series 2:
- SMA
- Connector 2 Gender:
- Female
- Connector 2 Gender 2:
- Male
- Download[PDF]:
- https://www.hasco-inc.com/content/Attenuators/HA18A5WS-dB_Datasheet.pdf
