SMA Male to SMA Male Ultra Low Loss Test Cable using HULL190 Flexible Cable, Phase Stable vs. Temp and Flexure, 30 Inches

$173.30
Part #:
HULL190-S1-S1-30
Brand:
HASCO Components
Weight:
2.50 Ounces
Shipping:
Calculated at checkout
Current Stock:
5

For quantities greater than current stock levels, please contact customer service at 1-888-498-3242

Pricing by Quantity:

QUANTITY

1 to 9

Buy 10 - 24

Buy 25 - 49

Buy 50 or above

PRICE

$173.30

$171.05

$168.09

$163.05

ADD TO WISHLIST

Description

HASCO Part Number: HULL190-S1-S1-30

RF Cable Assemblies offered by HASCO Components are available in a variety of RF connectors and custom lengths for production and testing environments.  HULL190-S1-S1-30 is an RF test cable manufactured by HASCO Components.  The RF cable used is HULL190, it is designed to be like the GORE ultra low loss. HULL190-S1-S1-30 has SMA Male to SMA Male connectors. This RF Assembly is rated up to 26.5 GHz. For additional technical information please refer to the datasheet. HASCO Cage Code: 0T8L4

pdf-icon.png« Click Here for the HULL190-S1-S1-30 Datasheetpdf-icon.png« Click Here for the HULL190-S1-S1-30 Outline Drawing

FEATURES:

  •  RoHS Compliant
  •  Low Loss, Low VSWR, High Reliability
  •  Phase Stable over Temp: 550ppm Max @ -45°C ~ +85°C
  •  Phase Stability Vs. Flexure: ± 4.5° @ 26.5GHz (When wrapped 360° around a 1.89" radius mandrel)
  •  Available with Stainless Steel Armor
  •  Cable Insertion Loss: -.39 dB per Ft @ 26.5 GHz
  •  Amplitude Stability: < ± 0.2 through 26.5 GHz

ELECTRICAL SPECIFICATIONS:

Max Frequency (GHz)

26.5









Capacitance (pF/ft)

23.7









Velocity Propagation (%)

85









RF Leakage @ 18 GHz (dB)











Time Delay (ns/Ft)

1.18









Impedance (Ohms)

50









Frequency (GHz)

2

6

12

18

26.5

Power CW (Watts)

650

390

260

220

190

Phase Stability vs. Flexure (°)

±0.33

±1

±2

±3

±4.5

MECHANICAL SPECIFICATIONS:

Cable Max Dia. (Inch)

0.189

Min. bend radius (Inch)

1.0

Recommend Bend Radius (Inch)

1.89

Temperature Range (°C)

-65 to +200

MATERIALS AND FINISHES:

DESCRIPTION

MATERIALS

FINISH OR COLOR

Cable Jacket

PFA

Grey

Marker

Mil-l-23053

White

Contacts

BeCu

Gold Plated

Insulators

PTFE

None

Connector Bodies

Stainless Steel

Passivated

Connector Nuts

Stainless Steel

Passivated

Gasket

Silicon Rubber

A-A-59588




Test #1: SMA Male to SMA Male, 24 inches, DC - 26.5 GHz



Test #2: SMA Male to SMA Male, 36 inches, DC - 26.5 GHz
*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242
Cable Diameter:
.189
Cable Length (Inch):
30
Cable Series:
HULL190
Cable Type:
Low Loss
Cable Type:
Phase Stable
Connector 1 Gender:
Male
Connector 1 Series:
SMA
Connector 1 Style:
Straight
Connector 2 Gender:
Male
Connector 2 Series:
SMA
Connector 2 Style:
Straight
Flex Type:
Flexible
Frequency, Max:
26.5 GHz
Frequency, Min:
DC
Jacket Material:
PFA
Type:
Standard Test
Velocity of Propogation (%):
85
PRODUCT DETAILS
HASCO Part Number: HULL190-S1-S1-30

RF Cable Assemblies offered by HASCO Components are available in a variety of RF connectors and custom lengths for production and testing environments.  HULL190-S1-S1-30 is an RF test cable manufactured by HASCO Components.  The RF cable used is HULL190, it is designed to be like the GORE ultra low loss. HULL190-S1-S1-30 has SMA Male to SMA Male connectors. This RF Assembly is rated up to 26.5 GHz. For additional technical information please refer to the datasheet. HASCO Cage Code: 0T8L4

pdf-icon.png« Click Here for the HULL190-S1-S1-30 Datasheetpdf-icon.png« Click Here for the HULL190-S1-S1-30 Outline Drawing

FEATURES:

  •  RoHS Compliant
  •  Low Loss, Low VSWR, High Reliability
  •  Phase Stable over Temp: 550ppm Max @ -45°C ~ +85°C
  •  Phase Stability Vs. Flexure: ± 4.5° @ 26.5GHz (When wrapped 360° around a 1.89" radius mandrel)
  •  Available with Stainless Steel Armor
  •  Cable Insertion Loss: -.39 dB per Ft @ 26.5 GHz
  •  Amplitude Stability: < ± 0.2 through 26.5 GHz

ELECTRICAL SPECIFICATIONS:

Max Frequency (GHz)

26.5









Capacitance (pF/ft)

23.7









Velocity Propagation (%)

85









RF Leakage @ 18 GHz (dB)











Time Delay (ns/Ft)

1.18









Impedance (Ohms)

50









Frequency (GHz)

2

6

12

18

26.5

Power CW (Watts)

650

390

260

220

190

Phase Stability vs. Flexure (°)

±0.33

±1

±2

±3

±4.5

MECHANICAL SPECIFICATIONS:

Cable Max Dia. (Inch)

0.189

Min. bend radius (Inch)

1.0

Recommend Bend Radius (Inch)

1.89

Temperature Range (°C)

-65 to +200

MATERIALS AND FINISHES:

DESCRIPTION

MATERIALS

FINISH OR COLOR

Cable Jacket

PFA

Grey

Marker

Mil-l-23053

White

Contacts

BeCu

Gold Plated

Insulators

PTFE

None

Connector Bodies

Stainless Steel

Passivated

Connector Nuts

Stainless Steel

Passivated

Gasket

Silicon Rubber

A-A-59588




Test #1: SMA Male to SMA Male, 24 inches, DC - 26.5 GHz



Test #2: SMA Male to SMA Male, 36 inches, DC - 26.5 GHz
WARRANTY INFORMATION
*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242
Part No: HULL190-S1-S1-30
SMA Male to SMA Male Ultra Low Loss Test Cable using HULL190 Flexible Cable, Phase Stable vs. Temp and Flexure, 30 Inches

HASCO Part Number: HULL190-S1-S1-30

RF Cable Assemblies offered by HASCO Components are available in a variety of RF connectors and custom lengths for production and testing environments.  HULL190-S1-S1-30 is an RF test cable manufactured by HASCO Components.  The RF cable used is HULL190, it is designed to be like the GORE ultra low loss. HULL190-S1-S1-30 has SMA Male to SMA Male connectors. This RF Assembly is rated up to 26.5 GHz. For additional technical information please refer to the datasheet. HASCO Cage Code: 0T8L4

pdf-icon.png« Click Here for the HULL190-S1-S1-30 Datasheetpdf-icon.png« Click Here for the HULL190-S1-S1-30 Outline Drawing

FEATURES:

  •  RoHS Compliant
  •  Low Loss, Low VSWR, High Reliability
  •  Phase Stable over Temp: 550ppm Max @ -45°C ~ +85°C
  •  Phase Stability Vs. Flexure: ± 4.5° @ 26.5GHz (When wrapped 360° around a 1.89" radius mandrel)
  •  Available with Stainless Steel Armor
  •  Cable Insertion Loss: -.39 dB per Ft @ 26.5 GHz
  •  Amplitude Stability: < ± 0.2 through 26.5 GHz

ELECTRICAL SPECIFICATIONS:

Max Frequency (GHz)

26.5









Capacitance (pF/ft)

23.7









Velocity Propagation (%)

85









RF Leakage @ 18 GHz (dB)











Time Delay (ns/Ft)

1.18









Impedance (Ohms)

50









Frequency (GHz)

2

6

12

18

26.5

Power CW (Watts)

650

390

260

220

190

Phase Stability vs. Flexure (°)

±0.33

±1

±2

±3

±4.5

MECHANICAL SPECIFICATIONS:

Cable Max Dia. (Inch)

0.189

Min. bend radius (Inch)

1.0

Recommend Bend Radius (Inch)

1.89

Temperature Range (°C)

-65 to +200

MATERIALS AND FINISHES:

DESCRIPTION

MATERIALS

FINISH OR COLOR

Cable Jacket

PFA

Grey

Marker

Mil-l-23053

White

Contacts

BeCu

Gold Plated

Insulators

PTFE

None

Connector Bodies

Stainless Steel

Passivated

Connector Nuts

Stainless Steel

Passivated

Gasket

Silicon Rubber

A-A-59588




Test #1: SMA Male to SMA Male, 24 inches, DC - 26.5 GHz



Test #2: SMA Male to SMA Male, 36 inches, DC - 26.5 GHz

Part No: HULL190-S1-S1-30
LTR
DESCRIPTION
DATE
APPR
THIS DRAWING IS A CONTROLLED DOCUMENT
DRAWN BY:
CHECKED BY:
APPROVED BY:
THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF HASCO COMPONENTS AND SHALL NOT BE REPRODUCED, COPIED NOR USED - IN WHOLE OR IN PART - AS THE BASIS FOR THE MANUFACTURE OR SALE OF OTHER ITEMS WITHOUT THE EXPRESS, RITTEN PERMISSION OF HASCO COMPONENTS.

MATERIALS:

SEE DATA SHEET

CAGE CODE:

HULL190-S1-S1-30

MATERIALS:

SEE DATA SHEET

SCALE:

NS

SIZE:

REV:
