Description
Features
• RoHs Compliant
• Low Loss
• Phase Stable
The HASCO HLL145R Series Cable is a low loss LL145R cable that operates from DC to 145 GHz. This cable series is constructed with 0.8mm Female to 0.8mm Female connectors. These cables are internally ruggedized with multi-layer copper spiral and braided armor. They offer excellent phase and amplitude stability vs. flexure. HASCO Cage Code: 0T8L4
« DatasheetSpecifications
Item |
Specification |
|---|---|
|
Frequency Range |
DC - 145 GHz |
|
Impedance |
50 Ω |
|
Insertion Loss |
22* L(M)+0.9 dB @ 145 GHz Max |
|
VSWR |
1.50:1 Max |
|
Dielectric Withstanding Voltage |
500V |
|
Insulation Resistance |
1000 MΩ |
Mechanical Specifications
Item |
Specification |
|---|---|
|
Min Bend Radius |
50mm Repeated |
|
Durability |
1000 Cycles |
Environmental Specifications
Item |
Specification |
|---|---|
|
Temperature Range |
-55°C to 85°C |
Material Specifications
Item |
Specification |
|---|---|
|
Connector Body & Nut |
Passivated Stainless Steel |
|
Dielectric |
PEI |
|
Center Contact |
Gold plated BeCu |
| Part # | Length | Insertion Loss (dB) |
| HLL145R-08J-08J-4 | 4" | ≦ 3.2 dB |
| HLL145R-08J-08J-6 | 6" | ≦ 4.3 dB |
| HLL145R-08J-08J-8 | 8" | ≦ 5.4 dB |
| HLL145R-08J-08J-9 | 9" | ≦ 6 dB |
| HLL145R-08J-08J-10 | 10" | ≦ 6.5 dB |
| HLL145R-08J-08J-12 | 12" | ≦ 7.7 dB |
| HLL145R-08J-08J-13 | 13" | ≦ 8.2 dB |
| HLL145R-08J-08J-16 | 16" | ≦ 9.9 dB |
| HLL145R-08J-08J-18 | 18" | ≦ 11 dB |
| HLL145R-08J-08J-24 | 24" | ≦ 14.4 dB |
- Cable Length (Inch):
- 4
- Cable Series:
- HLL145R
- Cable Type:
- Ruggedized
- Cable Type:
- Low Loss
- Connector 1 Gender:
- Female
- Connector 1 Series:
- 0.8mm
- Connector 1 Style:
- Straight
- Connector 2 Gender:
- Female
- Connector 2 Series:
- 0.8mm
- Connector 2 Style:
- Straight
- Flex Type:
- Ruggedized
- Frequency, Max:
- 145 GHz
- Frequency, Min:
- DC
