SMA Male to SMA Male Ultra Low Loss Test Cable using HULL320 Flexible Cable, Phase Stable vs. Temp and Flexure, 30 Inches

HULL320-S1-S1-30 main view for SMA Male to SMA Male Ultra Low Loss Test Cable using HULL320 Flexible Cable, Phase Stable vs. Temp and Flexure, 30 Inches - HASCO Components
  • HULL320-S1-S1-30 main view for SMA Male to SMA Male Ultra Low Loss Test Cable using HULL320 Flexible Cable, Phase Stable vs. Temp and Flexure, 30 Inches - HASCO Components
  • HULL320-S1-S1-30 catalog view for SMA Male to SMA Male Ultra Low Loss Test Cable using HULL320 Flexible Cable, Phase Stable vs. Temp and Flexure, 30 Inches - HASCO Components
  • HULL320-S1-S1-30 datasheet for SMA Male to SMA Male Ultra Low Loss Test Cable using HULL320 Flexible Cable, Phase Stable vs. Temp and Flexure, 30 Inches - HASCO Components

SMA Male to SMA Male Ultra Low Loss Test Cable using HULL320 Flexible Cable, Phase Stable vs. Temp and Flexure, 30 Inches

Sale Price:
$190.75
Model #:
HULL320-S1-S1-30
Brand:
HASCO Components
Weight:
5.00 Ounces
Part Number:
HULL320-S1-S1-30
Shipping:
Calculated at checkout
Current Stock:
5

*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242

Quantity:


Product Description

HASCO Part Number: HULL320-S1-S1-30

RF Cable Assemblies offered by HASCO Components are available in a variety of RF connectors and custom lengths for production and testing environments.  HULL320-S1-S1-30 is an RF test cable manufactured by HASCO Components.  The RF cable used is HULL320, it is designed to be like the GORE ultra low loss. HULL320-S1-S1-30 has SMA Male to SMA Male connectors. This RF Assembly is rated up to 18 GHz. For additional technical information please refer to the datasheet. Insulated Wire Cage Code: 59528

pdf-icon.pngClick Here for the HULL320-S1-S1-30 Datasheet  pdf-icon.pngClick Here for the HULL320-S1-S1-30 Outline Drawing

FEATURES:

  •  RoHs Compliant

  •  Low Loss, Low VSWR, High Reliability

  •  Phase Stable over Temp: 550ppm Max @ -45°C ~ +85°C

  •  Phase Stability Vs. Flexure: ± 4.5° @ 18 GHz
    (When wrapped 360°around a 3.2 radius mandrel)

  •  Available with Stainless Steel Armor

  •  Cable Insertion Loss: -.192 dB per Ft @ 18 GHz

  •  Amplitude Stability: < ± 0. 1 through 18 GHz

ELECTRICAL SPECIFICATIONS:

Max Frequency (GHz)

18









Capacitance (pF/ft)

23.7









Velocity Propagation (%)

85









RF Leakage @ 18 GHz (dB)











Time Delay (ns/Ft)

1.19









Impedance (Ohms)

50









Frequency (GHz)

2

6

10

18



Power CW (Watts)

1480

840

650

480



Phase Stability vs. Flexure (°)

±0.5

±1.5

±2.5

±4.5



MECHANICAL SPECIFICATIONS:

Cable Max Dia. (Inch)

0.319

Min. bend radius (Inch)

1.6

Recommend Bend Radius (Inch)

3.19

Temperature Range (°C)

-65 to +200

MATERIALS AND FINISHES:

DESCRIPTION

MATERIALS

FINISH OR COLOR

Cable Jacket

PFA

Grey

Marker

Mil-l-23053

White

Contacts

BeCu

Gold Plated

Insulators

PTFE

None

Connector Bodies

Stainless Steel

Passivated

Connector Nuts

Stainless Steel

Passivated

Gasket

Silicon Rubber

A-A-59588



Test #1: SMA Male to SMA Male, 24 inches, DC - 18 GHz



Test #2: SMA Male to SMA Male, 24 inches, DC - 18 GHz
