SMA Male to SMA Male Ultra Low Loss Test Cable using HULL320 Flexible Cable, Phase Stable vs. Temp and Flexure, 36 Inches

$293.95
Part #:
HULL320-S1-S1-36
Brand:
HASCO Components
Weight:
5.00 Ounces
Shipping:
Calculated at checkout
Current Stock:
4

For quantities greater than current stock levels, please contact customer service at 1-888-498-3242

Pricing by Quantity:

QUANTITY

1 to 9

10 to 24

25 to 49

50 or above

PRICE

$293.95

$225.95

$219.20

$212.60

ADD TO WISHLIST

Description

HASCO Part Number: HULL320-S1-S1-36

RF Cable Assemblies offered by HASCO Components are available in a variety of RF connectors and custom lengths for production and testing environments.  HULL320-S1-S1-36 is an RF test cable manufactured by HASCO Components.  The RF cable used is HULL320, it is designed to be like the GORE ultra low loss. HULL320-S1-S1-36 has SMA Male to SMA Male connectors. This RF Assembly is rated up to 18 GHz. For additional technical information please refer to the datasheet. HASCO Cage Code: 0T8L4

pdf-icon.png « Click Here for the HULL320-S1-S1-36 Datasheetpdf-icon.png« Click Here for the HULL320-S1-S1-36 Outline Drawing

FEATURES:

  •  RoHS Compliant
  •  Low Loss, Low VSWR, High Reliability
  •  Phase Stable over Temp: 550ppm Max @ -45°C ~ +85°C
  •  Phase Stability Vs. Flexure: ± 4.5° @ 18 GHz (When wrapped 360° around a 3.2 radius mandrel
  •  Available with Stainless Steel Armor
  •  Cable Insertion Loss: -.192 dB per Ft @ 18 GHz
  •  Amplitude Stability: < ± 0. 1 through 18 GHz

ELECTRICAL SPECIFICATIONS:

Max Frequency (GHz)

18









Capacitance (pF/ft)

23.7









Velocity Propagation (%)

85









RF Leakage @ 18 GHz (dB)











Time Delay (ns/Ft)

1.19









Impedance (Ohms)

50









Frequency (GHz)

2

6

10

18



Power CW (Watts)

1480

840

650

480



Phase Stability vs. Flexure (°)

±0.5

±1.5

±2.5

±4.5



MECHANICAL SPECIFICATIONS:

Cable Max Dia. (Inch)

0.319

Min. bend radius (Inch)

1.6

Recommend Bend Radius (Inch)

3.19

Temperature Range (°C)

-65 to +200

MATERIALS AND FINISHES:

DESCRIPTION

MATERIALS

FINISH OR COLOR

Cable Jacket

PFA

Grey

Marker

Mil-l-23053

White

Contacts

BeCu

Gold Plated

Insulators

PTFE

None

Connector Bodies

Stainless Steel

Passivated

Connector Nuts

Stainless Steel

Passivated

Gasket

Silicon Rubber

A-A-59588




Test #1: SMA Male to SMA Male, 24 inches, DC - 18 GHz



Test #2: SMA Male to SMA Male, 24 inches, DC - 18 GHz
*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242
Type:
Coax Cable Assemblies
Style:
Test Cable Assemblies
Application:
SMA Male to SMA Male Cable Assemblies
Construction:
Low Loss
Connector 1:
SMA Male
Connector 2:
SMA Male
Length (in.):
36
Impedance (Ohms):
50
Max Frequency (GHz):
18
Series:
HULL320
PRODUCT DETAILS
HASCO Part Number: HULL320-S1-S1-36

RF Cable Assemblies offered by HASCO Components are available in a variety of RF connectors and custom lengths for production and testing environments.  HULL320-S1-S1-36 is an RF test cable manufactured by HASCO Components.  The RF cable used is HULL320, it is designed to be like the GORE ultra low loss. HULL320-S1-S1-36 has SMA Male to SMA Male connectors. This RF Assembly is rated up to 18 GHz. For additional technical information please refer to the datasheet. HASCO Cage Code: 0T8L4

pdf-icon.png « Click Here for the HULL320-S1-S1-36 Datasheetpdf-icon.png« Click Here for the HULL320-S1-S1-36 Outline Drawing

FEATURES:

  •  RoHS Compliant
  •  Low Loss, Low VSWR, High Reliability
  •  Phase Stable over Temp: 550ppm Max @ -45°C ~ +85°C
  •  Phase Stability Vs. Flexure: ± 4.5° @ 18 GHz (When wrapped 360° around a 3.2 radius mandrel
  •  Available with Stainless Steel Armor
  •  Cable Insertion Loss: -.192 dB per Ft @ 18 GHz
  •  Amplitude Stability: < ± 0. 1 through 18 GHz

ELECTRICAL SPECIFICATIONS:

Max Frequency (GHz)

18









Capacitance (pF/ft)

23.7









Velocity Propagation (%)

85









RF Leakage @ 18 GHz (dB)











Time Delay (ns/Ft)

1.19









Impedance (Ohms)

50









Frequency (GHz)

2

6

10

18



Power CW (Watts)

1480

840

650

480



Phase Stability vs. Flexure (°)

±0.5

±1.5

±2.5

±4.5



MECHANICAL SPECIFICATIONS:

Cable Max Dia. (Inch)

0.319

Min. bend radius (Inch)

1.6

Recommend Bend Radius (Inch)

3.19

Temperature Range (°C)

-65 to +200

MATERIALS AND FINISHES:

DESCRIPTION

MATERIALS

FINISH OR COLOR

Cable Jacket

PFA

Grey

Marker

Mil-l-23053

White

Contacts

BeCu

Gold Plated

Insulators

PTFE

None

Connector Bodies

Stainless Steel

Passivated

Connector Nuts

Stainless Steel

Passivated

Gasket

Silicon Rubber

A-A-59588




Test #1: SMA Male to SMA Male, 24 inches, DC - 18 GHz



Test #2: SMA Male to SMA Male, 24 inches, DC - 18 GHz
WARRANTY INFORMATION
*** FOR QUANTITIES GREATER THAN CURRENT STOCK LEVELS CONTACT CUSTOMER SERVICE 1-888-498-3242
Part No: HULL320-S1-S1-36
SMA Male to SMA Male Ultra Low Loss Test Cable using HULL320 Flexible Cable, Phase Stable vs. Temp and Flexure, 36 Inches

HASCO Part Number: HULL320-S1-S1-36

RF Cable Assemblies offered by HASCO Components are available in a variety of RF connectors and custom lengths for production and testing environments.  HULL320-S1-S1-36 is an RF test cable manufactured by HASCO Components.  The RF cable used is HULL320, it is designed to be like the GORE ultra low loss. HULL320-S1-S1-36 has SMA Male to SMA Male connectors. This RF Assembly is rated up to 18 GHz. For additional technical information please refer to the datasheet. HASCO Cage Code: 0T8L4

pdf-icon.png « Click Here for the HULL320-S1-S1-36 Datasheetpdf-icon.png« Click Here for the HULL320-S1-S1-36 Outline Drawing

FEATURES:

  •  RoHS Compliant
  •  Low Loss, Low VSWR, High Reliability
  •  Phase Stable over Temp: 550ppm Max @ -45°C ~ +85°C
  •  Phase Stability Vs. Flexure: ± 4.5° @ 18 GHz (When wrapped 360° around a 3.2 radius mandrel
  •  Available with Stainless Steel Armor
  •  Cable Insertion Loss: -.192 dB per Ft @ 18 GHz
  •  Amplitude Stability: < ± 0. 1 through 18 GHz

ELECTRICAL SPECIFICATIONS:

Max Frequency (GHz)

18









Capacitance (pF/ft)

23.7









Velocity Propagation (%)

85









RF Leakage @ 18 GHz (dB)











Time Delay (ns/Ft)

1.19









Impedance (Ohms)

50









Frequency (GHz)

2

6

10

18



Power CW (Watts)

1480

840

650

480



Phase Stability vs. Flexure (°)

±0.5

±1.5

±2.5

±4.5



MECHANICAL SPECIFICATIONS:

Cable Max Dia. (Inch)

0.319

Min. bend radius (Inch)

1.6

Recommend Bend Radius (Inch)

3.19

Temperature Range (°C)

-65 to +200

MATERIALS AND FINISHES:

DESCRIPTION

MATERIALS

FINISH OR COLOR

Cable Jacket

PFA

Grey

Marker

Mil-l-23053

White

Contacts

BeCu

Gold Plated

Insulators

PTFE

None

Connector Bodies

Stainless Steel

Passivated

Connector Nuts

Stainless Steel

Passivated

Gasket

Silicon Rubber

A-A-59588




Test #1: SMA Male to SMA Male, 24 inches, DC - 18 GHz



Test #2: SMA Male to SMA Male, 24 inches, DC - 18 GHz

Part No: HULL320-S1-S1-36
LTR
DESCRIPTION
DATE
APPR
THIS DRAWING IS A CONTROLLED DOCUMENT
DRAWN BY:
CHECKED BY:
APPROVED BY:
THESE DRAWINGS AND SPECIFICATIONS ARE THE PROPERTY OF HASCO COMPONENTS AND SHALL NOT BE REPRODUCED, COPIED NOR USED - IN WHOLE OR IN PART - AS THE BASIS FOR THE MANUFACTURE OR SALE OF OTHER ITEMS WITHOUT THE EXPRESS, RITTEN PERMISSION OF HASCO COMPONENTS.

MATERIALS:

SEE DATA SHEET

CAGE CODE:

HULL320-S1-S1-36

MATERIALS:

SEE DATA SHEET

SCALE:

NS

SIZE:

REV:
